Application of Real Size Film Printing Technology in Costal Cartilage CT Image
-
摘要: 目的：探索在医用胶片上对肋软骨CT影像显示其真实大小的胶片打印技术。方法：选取31例患者肋软骨CT影像资料，经影像后处理，胶片采用14英寸×17英寸（35 cm×43 cm）规格，计算EBW工作站显示屏主影像显示区和14×17胶片上实际影像显示区之间的比例关系，制成10 cm和5 cm两个长度规格的实物比例尺。打印时将胶片以2×2分格呈4幅图像布局，选取5 cm实物比例尺打印单根肋软骨横轴面或矢状面影像；以1×1分格呈单幅图像布局，选取10 cm实物比例尺打印全部前肋弓（含肋软骨）的三维影像。选取右侧第6肋软骨升部、横部的长度，升部横部连接处宽度、厚度，肋软骨胸骨端、肋软骨肋骨端的厚度等6个指标的胶片测量值和手术中实体测量值进行比较，并做统计学分析。结果：①对已打印的胶片进行测量，胶片上所示10 cm和5 cm比例尺与直尺的实际尺寸相等；②胶片上肋软骨影像的 6组测量值和手术中的肋软骨实体测值对比，测量值差异无统计学意义。结论：基于DICOM协议下的打印技术可以实现肋软骨CT影像在胶片上的真实大小打印，术者从胶片中所获取的目标组织的形态数据可靠。Abstract: Objective: To explore the film printing technology for displaying the true size of costal cartilage on medical film. Methods: The CT images of costal cartilage of 31 patients were selected and processed 14×17 inches (35×43 cm), calculate the main image display area and 14×17 the scale between the actual image display areas on the film shall be made into physical scales of 10 cm and 5 cm in length. Print the film in 2×2. Four images are arranged in the grid, and the transverse or sagittal images of single rib cartilage are printed on a 5 cm physical scale; with 1×1 The grid is a single image layout, and the 3D images of all the front rib arches (including costal cartilage) are printed on a 10 cm physical scale. The film measurement values of six indicators, including the length of the ascending and transverse parts of the right sixth costal cartilage, the width and thickness of the transverse junction of the ascending part, the thickness of the sternal end of the costal cartilage and the rib end of the costal cartilage, were compared with the solid measurement values during the operation, and statistical analysis was made. Results: (1) The printed film was measured, and the 10 cm and 5 cm scales shown on the film were equal to the actual size of the ruler. (2) There was no significant difference between the measured values of six groups of costal cartilage images on film and the measured values of costal cartilage entities during surgery. Conclusion: The printing technology based on DICOM protocol can realize the real size printing of costal cartilage CT image on film. The morphological data of the target tissue obtained by the operator from the film are reliable.
-
Key words:
- CT Image /
- costal cartilage /
- true size /
- film printing
-
图 3 利用5 cm和10 cm实物比例尺在胶片上打印肋软骨真实大小影像
Figure 3. Print the true size image of costal cartilage on filsm with 5 cm and 10 cm physical scales
图 5 在胶片上测量右侧第6肋软骨胸骨端厚度（矢冠轴3图以十字线同步定位）
Figure 5. The measure the thickness of the sternal end of the sixth costal cartilage on the film
图 6 右侧第6肋软骨胸骨端术中实体测量厚度
Figure 6. The measured thickness of the sternal end of the sixth costal cartilage on the right during operation
表 1 肋软骨6个相同位置胶片测量值和人体测量值差异统计
Table 1. Difference statistics of film measurement value and human measurement value at five same positions of costal cartilage
分类 胶片测量值（均数±标准差） 统计检验 实体 胶片 t P 肋软骨升部长度/cm 77.46±13.46 77.84±13.45 -0.07 0.94 肋软骨横部长度/cm 33.44±5.49 33.24±5.85 0.09 0.93 升部横部连接处宽度/cm 15.83±1.94 15.80±2.24 0.03 0.98 升部横部连接处厚度/cm 5.95±1.77 5.96±1.77 -0.01 0.99 肋软骨胸骨端厚度/cm 12.05±2.50 12.02±2.49 0.03 0.98 肋软骨肋骨端厚度/cm 8.48±1.11 8.49±1.02 -0.04 0.97
下载: 导出CSV
-
[1] VON G H, FISCHER H, EPPSSTEIN R, et al. Framework fabrication with rib eartilage in partial and total nasal reconstruction[J]. Facial Plastic Surgery, 2014, 30(3): 306−317. DOI: 10.1055/s-0034-1376876. [2] 周佳宇, 林琳, 蒋海越, 等. 个性化肋软骨采集及其耳支架雕刻[J]. 中华耳科学杂志, 2013,11(4): 502−505. DOI: 10.3969/j.issn.1672-2922.2013.04.008.ZHOU J Y, LIN L, JIANG H Y, et al. Individualized fabrication and application of autogenous cartilage framework in auricular reconstruction[J]. Chinese Journal of Otology, 2013, 11(4): 502−505. DOI: 10.3969/j.issn.1672-2922.2013.04.008. (in Chinese). [3] 王少健, 陈娇, 丁忠祥, 等. 螺旋CT三维后处理技术在肋软骨骨折诊断中的价值[J]. 中华创伤杂志2020, 36(1): 78-81. DOI: 10.3760/cma.j.issn.1001-8-50.2020.01.016.WANG S J, CHEN J, DING Z X, et al. The value of spiral CT three-dimensional post-processing technique in the diagnosis of costal cartilage fracture[J]. Chinese Journal of Trauma, 2020, 36(1): 78-81. DOI:10.3760/cma.j.issn.1001-8-50.2020.01.016. (in Chinese). [4] 何乐人, 杨庆华, 蒋海越, 等. 小耳畸形八大处法耳廓再造术−团队10年经验[J]. 中华整形外科杂志, 2017,33(8): 30−35. DOI: 10.3760/cma.j.issn.1009-4598.2017.s1.007.HE L R, YANG Q H, JIANG H Y, et al. Ear reconstruction with Ba-Da-Chu method: Ten-year experiences of our team[J]. Chinese Journal of Plastic Surgery, 2017, 33(8): 30−35. DOI: 10.3760/cma.j.issn.1009-4598.2017.s1.007. (in Chinese). [5] 毛小明, 蒋廷宠. 低场MR对肋软骨损伤的检查价值[J]. 实用放射学杂志, 2011,27(4): 644−645. DOI: 10.3969/j.issn.1002-1671.2011.04.050.MAO X M, JIANG T C. Costal cartilage injury: Evaluation by low-field magnetic resonance imaging[J]. Journal of Practical Radiology, 2011, 27(4): 644−645. DOI: 10.3969/j.issn.1002-1671.2011.04.050. (in Chinese). [6] 王永振, 何乐人, 刘雳, 等. 多层螺旋CT扫描及三维重建技术在肋软骨组织量评估中的应用研究[J]. 中国修复重建外科杂志, 2014,28(10): 1266−1269. DOI: 10.7507/1002-1892.20140274.WANG Y Z, HE L R, LIU L, et al. Evaluationof multi-slice spiral CT scanand image reconstruction technology ineetimating costal cartilage volume[J]. Chinese Journal of Reparative and Reconstructive Surgery, 2014, 28(10): 1266−1269. DOI: 10.7507/1002-1892.20140274. (in Chinese). [7] 刘雳, 李博, 曹捷, 等. 儿童肋软骨MSCT扫描后三种三维成像技术的比较[J]. 中华整形外科杂志, 2017,33(5): 363−366. DOI: 10.3760/cma.j.issn.1009-4598.2017.05.009.LIU L, LI B, CAO J, et al. Comparison of three 3D imaging techniques in children with costal cartilage MSCT scan[J]. Chinese Journal of Plastic Surgery, 2017, 33(5): 363−366. DOI: 10.3760/cma.j.issn.1009-4598.2017.05.009. (in Chinese). [8] 魏忠荣, 陈涛, 戴维思, 等. 多层螺旋CT及Cardiac 1预设重建模式对肋软骨骨折的诊断价值[J]. 实用放射学杂志, 2020,36(3): 472−474, 490. DOI: 10.3969/j.issn.1002-1671.2020.03.033.WEI Z R, CHEN T, DAI W S, et al. The diagnostic value of MSCT and the preset reconstruction model of cardiac 1 in costal cartilage fractures[J]. Journal of Practical Radiology, 2020, 36(3): 472−474, 490. DOI: 10.3969/j.issn.1002-1671.2020.03.033. (in Chinese). [9] 路涛, 蒲红, 杨诚, 等. 多层螺旋CT容积重建技术在儿童鸡胸中的应用价值[J]. 实用放射学杂志, 2016,32(7): 1088−1091. DOI: 10.3969/j.issn.1002-1671.2016.07.025.LU T, PU H, YANG C, et al. Value of volume rendering technique of MSCT in the diagnosis of pediatric pectus carinatum[J]. Journal of Practical Radiology, 2016, 32(7): 1088−1091. DOI: 10.3969/j.issn.1002-1671.2016.07.025. (in Chinese). [10] 王立振, 李秀涛, 吕涵青. 多层螺旋CT三维重建在肋骨及肋软骨的应用体会[J]. 中国CT和MRI杂志, 2018,16(2): 124−126. DOI: 10.3696/j.issn.1672-5131.2018.03.039.WANG L Z, LI X T, LV H Q. Multislice spiral CT three-dimensional reconstruction of bone in rib and costal cartilage experience[J]. Chinese Journal of CT and MRI, 2018, 16(2): 124−126. DOI: 10.3696/j.issn.1672-5131.2018.03.039. (in Chinese). [11] 周晨钟. CR系统在四肢床旁片应用价值的研究[J]. 临床和实验医学杂志, 2012,11(1): 63−64. DOI: 10.3969/j.issn.1671-4695.2012.01.032.ZHOU C Z. Study on the application value of CR system in bedside films of limbs[J]. Journal of Clinical and Experimental Medicine, 2012, 11(1): 63−64. DOI: 10.3969/j.issn.1671-4695.2012.01.032. (in Chinese). [12] 宋玉全, 何志诚, 伍筱梅, 等. 斜射线摄影对直接数字化X线摄影系统影像质量的影响评价[J]. 中华放射学杂志, 2005,39(10): 1084−1087. DOI: 10.3760/j.issn:1005-1201.2005.10.017.SONG Y Q, HE Z C, WU X M, et al. Effect of oblique ray on image quality of directdigitized radiography system[J]. Chinese Journal of Radiology, 2005, 39(10): 1084−1087. DOI: 10.3760/j.issn:1005-1201.2005.10.017. (in Chinese). [13] 汤婷, 张颖佳, 王继华, 等. 多层螺旋CT容积再现技术在肋软骨切取术中的应用[J]. 中华整形外科杂志, 2017,33(1): 57−60. DOI: 10.3760/cma.j.issn.1009-4598.2017.01.014.TANG T, ZHANG Y J, WANG J H, et al. Application of multi-slice spiral CT volume reconstruction technique in costal cartilage resection[J]. Chinese Journal of Plastic Surgery, 2017, 33(1): 57−60. DOI: 10.3760/cma.j.issn.1009-4598.2017.01.014. (in Chinese). [14] 徐遄, 吴勇, 贾克斌, 等. 数字医学影像与通信的重要标准−DICOM标准[J]. 中国医学影像技术, 2002,18(9): 952−954. doi: 10.13929/j.1003-3289.2002.09.058 [15] 邢文珊, 钱瑾, 胡金天, 等. 肋软骨等比例打印在耳廓支架构建中的应用[J]. 中华整形外科杂志, 2018,(3): 206−209. DOI: 10.3760/cam.j.issn.1009-4598.2018.03.010.XING W S, QIAN J, HU J T, et al. The application of a 2D printing of rib cartilage in personalized ear framework fabrication[J]. Chinese Journal of Plastic Surgery, 2018, (3): 206−209. DOI: 10.3760/cam.j.issn.1009-4598.2018.03.010. (in Chinese). [16] 苏扬, 刘静, 王江玥. 多层螺旋CT骨三维重建在肋骨及肋软骨骨折的诊断价值[J]. 中国CT和MRI杂志, 2016,14(7): 124−126. DOI: 10.3696/j.issn.1672-5131.2016.07.041.SU Y, LIU J, WANG J Y. The diagnostic value of multi-slice spiral CT 3D bone reconstruction on rib and rib cartilage fractures[J]. Chinese Journal of CT and MRI, 2016, 14(7): 124−126. DOI: 10.3696/j.issn.1672-5131.2016.07.041. (in Chinese). [17] SUNWOO W, CHOL H, KIM D, et al. Characteristics of rib cartilage al calcification in Asian[J]. JAMA Facial Plastic Surgery, 2014, 16(2): 102−106. DOI: 10.1001/jamafacial.2013.2031. -
