Application of a Contrast Enhancement Boost Technique in Cranial Four-dimensional Computed Tomography Angiography
-
摘要:
目的：本研究旨在探索柔性减影CE-Boost技术在头颅4D-CTA不同期相不同增强程度血管中的增强能力和适用范围。方法：回顾性分析43例接受脑灌注CTP检查的患者4D-CTA数据，依据主观评分标准从4D-CTA中选取一组动脉早期不可诊断图像和两组动脉期可诊断图像共3组CTA原始数据，用副台减影软件生成对应的CE-Boost组图像。测量六组图像大脑中动脉（MCA）M1段、基底动脉（BA）、脑干（BA），以CT值、图像噪声（SD）、信噪比（SNR）、对比噪声比（CNR）对CE-Boost技术前后图像进行客观评价。采用五分制法对图像进行主观评分。结果：全部图像CE-Boost组大脑中动脉、基底动脉的CT值、SD值、SNR、CNR高于原始图像，P均＜0.001。全部图像CE-Boost组主观打分高于原始图像（3.59±1.33 VS. 2.92±0.95，P<0.001）。结论：CE-Boost技术对颅内4D-CTA动脉期可诊断的图像在提高主干客观评价的同时也可以提高颅内分支小血管的显示。对于动脉早期不可诊断图像仅可提高主干的客观评价，对提升颅内分支小血管的显示能力有限。本研究建议CE-Boost技术适用于颅内主观评分大于等于3分的动脉期可诊断图像。
Abstract:PurposeThis study aimed to explore the efficacy and versatility of contrast enhancement boost (CE-Boost) technology for enhancing blood vessels with varying phases and degrees of enhancement on cranial four-dimensional computed tomography angiography (4D-CTA). Materials and Methods: Forty-three patients who underwent cerebral CT perfusion (CTP) were enrolled retrospectively. For each patient, three single-phase images were selected from the 4D-CTA based on subjective scoring criteria: one image was scored as arterial early phase non-diagnostic (insufficient enhancement for clinical diagnosis), and two images were scored as arterial phase diagnostic (sufficient enhancement for clinical diagnosis). Subsequently, the corresponding CE-Boost group images were generated using subtraction software. Measurements were obtained on the normal side in six image groups, including: the middle cerebral artery (MCA) M1 segment, basilar artery (BA), and brainstem (BS). Objective image quality was assessed using the CT value, image noise, signal-to-noise ratio (SNR), and contrast noise ratio (CNR). The subjective image quality was assessed using a five-point Likert scale.
ResultsThe CT attenuation value, noise value, SNR, and CNR of the MCA and BA were significantly higher in the CE-Boost group than in the original images (all P<0.001). The subjective score of the CE-Boost group was higher than that of the original image (3.59±1.33 versus 2.92±0.95, P<0.001).
ConclusionThe CE-Boost technique can improve the objective image quality of arterial phase diagnostic images of intracranial 4D-CTA while improving the visualization of branch vessels. However, arterial early phase non-diagnostic images only improve the objective evaluation of the trunk and have limited ability to improve the visualization of intracranial branch vessels. This study suggests that the CE-Boost technique is suitable for arterial phase diagnostic images with an intracranial subjective score greater than or equal to 3.
-
Keywords:
- X-ray computer /
- angiography /
- contrast enhancement
-
-
![]()
图 1 主观评分为2分、3分、4分原始图像行CE-Boost处理示例
Figure 1. The subjective score is 2 points, 3 points, and 4 points, and the original image is exemplified by CE-Boost processing
![]()
图 2 左侧颈内动脉闭塞，大脑中动脉延迟显影。主观评分为2分、3分、4分的原始图像行CE-Boost处理示例
Figure 2. Left internal carotid artery occlusion and delayed middle cerebral artery development. The subjective score is 2 points, 3 points, and 4 points, and the original image is exemplified by CE-Boost processing
表 1 不同主观评分原始图像与CE-Boost组客观图像质量评价比较
Table 1 Comparison of the objective image quality evaluation between the raw images with different subjective scores and the CE-Boost group
组别 CT值 SD SNR CNR MCA BA MCA BA MCA BA MCA BA 全部 原始图像 318.32
（136.83）280.82
（139.31）16.00
（10.55）13.02
（9.71）24.21
（11.43）28.20
（18.15）39.11
（24.09）34.00
（24.08）CE-Boost 444.70
（205.50）390.72
（205.00）19.55
（13.90）14.92
（12.61）30.27
（18.81）40.18
（32.28）61.23
（42.48）53.37
（42.42）P值 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 增长% 39.70 39.14 22.19 14.59 25.03 42.48 56.56 56.97 不可诊断图像1&2分 原始图像 165.05
（54.35）133.51
（56.40）8.08
（3.37）6.92
（3.75）23.45
（11.23）23.61
（13.78）18.68
（11.80）13.87
（9.85）CE-Boost 214.71
（80.29）173.36
（79.84）8.90
（4.08）7.06
（4.71）28.70
（15.94）32.01
（21.02）25.96
（17.52）19.66
（14.11）P值 <0.001 <0.001 <0.001 1.00 <0.001 <0.001 <0.001 <0.001 增长% 30.09 29.85 10.15 2.02 22.39 35.58 38.97 41.74 可诊断图像
3&4分原始图像 394.95
（94.38）354.48
（105.75）19.96
（10.70）16.08
（10.33）24.58
（11.58）30.49
（19.66）49.33
（22.10）44.07
（22.76）CE-Boost 559.69
（142.38）499.40
（155.83)24.88
（14.02）18.85
（13.48）31.05
（20.13）44.27
（36.06）78.87
（40.27）70.23
（41.82）P值 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 增长% 41.71 40.88 24.65 17.23 26.32 45.20 59.88 59.36 注：CE-Boost组与原始图像比较P＜0.05；增长%为与原始图像比较。
下载: 导出CSV
表 2 原始图像（列）与相对应的CE-Boost组图像（行）主观图像评价结果比较
Table 2 Comparison of subjective image evaluation results between the original images (columns） and the CE-Boost group (rows）.
组别 医师1/例 医师2/例 一致性分析 1 2 3 4 5 1 2 3 4 5 Kappa值 原始评分1分（10例） 10 10 0.890 原始评分2分（33例） 22 11 33 原始评分3分（43例） 10 33 43 原始评分4分（43例） 43 43
下载: 导出CSV
表 3 原始图像与CE-Boost组图像两名主观打分者评分结果
Table 3 Comparison of the scores of two subjective scorers between the original image and the CE-Boost group
全部 原始图像1&2分 原始图像3&4分 原始图像 CE-Boost P值 原始图像 CE-Boost P值 原始图像 CE-Boost P值 平均分 2.92±0.95 3.59±1.33 <0.001 1.77±0.43 1.90±0.54 0.001 3.50±0.50 4.44±0.59 <0.001 注：平均值±标准差，表示两名主观打分者对原始图像和CE-Boost组图像主观评分。
下载: 导出CSV
-
[1] 刘昊喆, 陈钰, 苏童, 等. 深度学习重建在低剂量颅脑CT灌注的研究[J]. 影像诊断与介入放射学, 2024, 33(1): 18−24. DOI: 10.3969/j.issn.1005-8001.2024.01.002. LIU H Z, CHEN Y, SU T, et al. Study of deep learning reconstruction algorithm in low-dose head CT perfusion[J]. Diagnostic Imaging and Interventional Radiology, 2024, 33(1): 18−24. DOI: 10.3969/j.issn.1005-8001.2024.01.002.
[2] 刘新立, 蒋元文, 陈敏, 等. 320排CT全脑血管成像的应用价值及扫描方法优化[J]. 放射学实践, 2012, 27(12): 1311−1315. DOI: 10.13609/j.cnki.1000-0313.2012.12.007. LIU X L, JIANG Y W, CHEN M, et al. Clinical value of 320-detector row CT whole-brain vascular angiography and optimization of the scanning method[J]. Radiologic Practice, 2012, 27(12): 1311−1315. DOI: 10.13609/j.cnki.1000-0313.2012.12.007.
[3] SMIT E J, VONKEN E-J, VAN D S I C, et al. Timing-invariant reconstruction for deriving high-quality CT angiographic data from cerebral CT perfusion data[J]. Radiology, 2012, 263(1): 216−25. DOI: 10.1148/radiol.11111068.
[4] WILLEMS P W A, TAESHINEETANAKUI P, SCHENK B et al. The use of 4D-CTA in the diagnostic work-up of brain arteriovenous malformations[J]. Neuroradiology, 2012, 54(2): 123−31. DOI: 10.1007/s00234-011-0864-0.
[5] HOOGENBOOM T C H, van B R M J, VAN T B, et al. Optimization of the reconstruction interval in neurovascular 4D-CTA imaging. A technical note[J]. Interventional neuroradiology: Journal of Peritherapeutic Neuroradiology, Surgical Procedures and Related Neurosciences, 2012, 18(4): 377−379. DOI: 10.1177/159101991201800402.
[6] 叶梅, 邢艳, 侯娟, 等. 模型迭代重建与柔性减影CE-Boost技术在肥胖患者CT肺动脉造影中的应用[J]. 影像诊断与介入放射学, 2024, 33(1): 25−30. YE M, XING Y, Application of model-based iterative reconstruction algorithm and contrast-enhancement boost postprocessing technique in CT pulmonary angiography of obese patients[J]. Diagnostic Imaging and Interventional Radiology, 2024, 33(1): 25−30. (in Chinese).
[7] JUAN H, YUAN Z, JING Y, et al. Clinical application of the contrast-enhancement boost technique in computed tomography angiography of the portal vein[J]. Abdominal radiology (New York), 2022, 48(2): 806−815. DOI: 10.1007/s00261-022-03754-4.
[8] JIA X, SHITIAN W, XUAN W, et al. Effects of contrast enhancement boost postprocessing technique in combination with different reconstruction algorithms on the image quality of abdominal CT angiography[J]. European Journal of Radiology, 2022, 154110388-110388. DOI: 10.1016/j.ejrad.2022.110388
[9] 王赫, 何良浩, 季文超, 等. 柔性减影CE-Boost技术对CT肺动脉造影图像质量的影响[J]. 中国介入影像与治疗学, 2022, 19(5): 296−299. DOI: 10.13929/j.issn.1672-8475.2022.05.009. WANG H, HE L H, JI W C, et al. Impact of flexible splicing CE-Boost technique on imaging quality of CT pulmonary angiography[J]. Chinese Journal of Interventional lmaging and Therapy, 2022, 19(5): 296−299. DOI: 10.13929/j.issn.1672-8475.2022.05.009.
[10] CHULUUNBAATAR O, PILHYUN J, JAEKYUN R, et al. The effectiveness of post-processing head and neck CT angiography using contrast enhancement boost technique[J]. PloS One, 2023, 18(4): e0284793−e0284793. DOI: 10.1371/journal.pone.0284793.
[11] 李俊超, 侯娟, 刘文亚, 等. 柔性减影CE-boost技术用于头颈部CT血管成像[J]. 中国医学影像技术, 2024, 40(3): 436−440. DOI: 10.13929/j.issn.1003-3289.2024.03.024. LI J C, HOU J, LIU W Y, et al. Flexible splicing CE-boost technique applicated in post-processing of head and neck CT angiography[J]. Chinese Journal of Medical Imaging Technology, 2024, 40(3): 436−440. DOI: 10.13929/j.issn.1003-3289.2024.03.024.
[12] YU C, YANLING W, TONG S, et al. Deep learning reconstruction improves the image quality of CT angiography derived from 80-kVp cerebral CT perfusion data[J]. Academic Radiology, 2023, 30(11): 2666−2673. DOI: 10.1016/j.acra.2023.02.007.
[13] CHRISTNER J A, KOFLER J M, MCCOLLOUGH C H. Estimating effective dose for CT using dose-length product compared with using organ doses: Consequences of adopting international commission on radiological protection publication 103 or dual-energy scanning[J]. AJR. American Journal of Roentgenology, 2010, 194(4): 881−889. DOI: 10.2214/AJR.09.3462.
[14] 朱玉才, 夏文文, 侯娟, 等. 柔性减影CE-Boost技术对下肢动脉CT血管造影图像质量的影响[J]. 中国介入影像与治疗学, 2023, 20(9): 561−565. 1672−8475. DOI: 10.13929/j.issn. ZHU Y C, XIA W W, HOU J, et al. Impact of flexible splicing CE-boost technique on imaging quality of CT angiography of lower extremity arteries[J]. Chinese Journal of Interventional Lmaging and Therapy, 2023, 20(9): 561−565. 1672−8475. DOI: 10.13929/j.issn.1672-8475.2023.09.012.
[15] IIZUKA H, YOKOTA Y, KIDOH M, et al. Contrast enhancement boost technique at aortic computed tomography angiography: Added value for the evaluation of type II endoleaks after endovascular aortic aneurysm repair[J]. Academic Radiology, 2019, 26(11): 1435−1440. DOI: 10.1016/j.acra.2019.01.009.
[16] CHULUUNBAATAR O, KYUN J R, HACKJOON S, et al. A novel computed tomography image reconstruction for improving visualization of pulmonary vasculature: Comparison between preprocessing and postprocessing images using a contrast enhancement boost technique[J]. Journal of Computer Assisted Tomography, 2022, 46(5): 729−734. DOI: 10.1097/RCT.0000000000001347.
[17] 王旭, 罗冬平, 郭晓凯, 等. 肾病患者碘对比剂应用共识解读[J]. 中国血液净化, 2020, 19(11): 775−778. WANG X, LUO D P, GUO X K, et al, Common interpretation of iodine contrast agents used in nephrotic patients[J], Chinese Journal of Blood Purification, 2020, 19(11): 775−778. (in Chinese).
[18] 牛晓旺, 郑娟, 杜世伟, 等. C臂CT在神经介入中的应用进展[J]. 中国介入影像与治疗学, 2015, 12(9): 573−576. DOI: 10.13929/j.1672-8475.2015.09.013. NIU X W, ZHENG J DU S W, et al. Progresses of C-arm CT utilization in interventional neuroradiology[J]. Chinese Journal of Interventional lmaging and Therapy, 2015, 12(9): 573−576. DOI: 10.13929/j.1672-8475.2015.09.013.
[19] 吕发金, 罗天友, 谢鹏, 等. 数字减影CTA图像质量影响因素探讨[J]. 重庆医科大学学报, 2007(3): 271−274. DOI: 10.3969/j.issn.0253-3626.2007.03.014. LV F J, LUO T Y, XIE P, et al. Digital subtraction CT Angiography (DS CTA): Influencing factors for image quality[J]. Journal of Chongqing Medical University, 2007(3): 271−274. DOI: 10.3969/j.issn.0253-3626.2007.03.014. (in Chinese).
