双气相定量CT对轻中度COPD的评估价值研究

王雄慧, 潘娟, 牛媛, 沈敏, 阴玮灵, 李建龙, 黄晓旗, 郭佑民

王雄慧, 潘娟, 牛媛, 等. 双气相定量CT对轻中度COPD的评估价值研究[J]. CT理论与应用研究(中英文), 2024, 33(2): 189-196. DOI: 10.15953/j.ctta.2022.189.
引用本文: 王雄慧, 潘娟, 牛媛, 等. 双气相定量CT对轻中度COPD的评估价值研究[J]. CT理论与应用研究(中英文), 2024, 33(2): 189-196. DOI: 10.15953/j.ctta.2022.189.
WANG X H, PAN J, NIU Y, et al. The Research Value of Biphasic Registration Quantitative Computed Tomography Emphysema Index in the Evaluation of Mild to Moderate COPD[J]. CT Theory and Applications, 2024, 33(2): 189-196. DOI: 10.15953/j.ctta.2022.189. (in Chinese).
Citation: WANG X H, PAN J, NIU Y, et al. The Research Value of Biphasic Registration Quantitative Computed Tomography Emphysema Index in the Evaluation of Mild to Moderate COPD[J]. CT Theory and Applications, 2024, 33(2): 189-196. DOI: 10.15953/j.ctta.2022.189. (in Chinese).

双气相定量CT对轻中度COPD的评估价值研究

基金项目: 陕西省重点研发计划一般项目(基于体素对吸烟者肺结构损伤的定量研究(2021SF-254))。
详细信息
    作者简介:

    王雄慧: 男,延安大学在读硕士,研究方向为胸部影像学,E-mail:1563059126@qq.com

    通讯作者:

    潘娟: 女,延安市人民医院副主任医师,主要从事临床诊断工作,E-mail:745778215@qq.com

  • 中图分类号: R  814

The Research Value of Biphasic Registration Quantitative Computed Tomography Emphysema Index in the Evaluation of Mild to Moderate COPD

  • 摘要:

    目的:通过配准的双气相定量CT对轻中度慢性阻塞性肺疾病(COPD)患者肺气肿定量指标的对比分析,寻找最优肺气肿定量指标。方法:回顾性收集健康体检对照组55例和慢性阻塞性肺疾病全球倡议(GOLD)1级21例,GOLD 2级31例。将CT原始DICOM数据导入“数字肺”分析平台,测定深吸气末LAA%-950和深呼气末 LAA%-910。将呼气相与吸气相CT图像配准,根据阈值法计算出肺气肿区域百分比(PRMEmph%)、功能性小气道病变区域百分比(PRMfSAD%)和正常区域百分比(PRMNormal%)。肺功能指标包括FVC、FEV1%、FEV1/FVC。组间一般资料、CT定量指标和肺功能差异采用独立样本t检验、Mann-Whitney U检验或卡方检验,相关性采用Spearman相关分析。绘制受试者工作特征(ROC)曲线分析CT定量参数对轻中度COPD患者肺气肿的诊断效能。结果:轻中度COPD患者与正常对照组间性别、吸烟指数、FEV1%、FEV1/FVC、吸气相LAA%-950、呼气相LAA%-910、PRMEmph%、PRMfSAD%及 PRMNormal%差异均有统计学意义。吸气相LAA%-950与FEV1/FVC呈负相关,呼气相LAA%-910、PRMEmph%与FVC、FEV1%、FEV1/FVC均呈负相关。ROC曲线分析结果显示吸气相LAA%-950、呼气相LAA%-910及PRMEmph%曲线下面积分别为 0.742、0.861、0.876,其中PRMEmph%指标的曲线下面积最大,对应临界值为9.84%,敏感度76.90%,特异度94.50%。结论:定量CT肺气肿指标吸气相LAA%-950、呼气相LAA%-910及双气相 PRMEmph%都能够客观评估轻中度COPD患者的肺气肿情况,其中PRMEmph%是最优评估指标。

    Abstract:

    Objective: To find the optimal quantitative index of emphysema by comparing and analyzing the quantitative indexes of emphysema in patients with mild to moderate chronic obstruction pulmonary disease (COPD) via registered biphasic quantitative computed tomography (QCT). Methods: We retrospectively collected 55 healthy controls, 21 Global Initiative for Chronic Obstructive Pulmonary Disease (GOLD) 1 case, and 31 GOLD 2 cases in our hospital. We imported the CT raw DICOM data into the "Digital Lung" analysis platform and measured the LAA-950% at the end of deep inspiration and the LAA-910% at the end of deep expiration. The expiratory and inspiratory CT images were registered. Then, the percentage of emphysema area (PRMEmph%), the percentage of functional small airway disease area (PRMfSAD%), and the percentage of the normal area (PRMNormal%) were calculated according to the threshold method. Pulmonary function indicators included FVC, FEV1%, and FEV1/FVC. Differences in general data, CT quantitative indexes, and pulmonary function between groups were assessed using the independent sample t-test, Mann–Whitney U test, or chi-square test, and the correlation was analyzed using Spearman correlation. The receiver operating characteristic (ROC) curve was drawn to analyze the diagnostic performance of CT quantitative parameters for emphysema in patients with mild to moderate COPD. Results: There were significant differences in sex, smoking index, FEV1%, FEV1/FVC, inspiratory phase LAA%-950, expiratory phase LAA%-910, PRMEmph%, PRMfSAD%, and PRMNormal% between the mild to moderate COPD patients and normal control groups. The inspiratory phase LAA%-950 was negatively correlated with FEV1/FVC, the expiratory phase LAA%-910 and PRMEmph% were negatively correlated with FVC, FEV1%, and FEV1/FVC. ROC curve analysis results showed that the areas under the curve of inspiration phase LAA%-950, expiratory phase LAA%-910, and PRMEmph% were 0.742, 0.861, and 0.876, respectively. Among them, the area under the curve of the PRMEmph% index was the largest, with a corresponding critical value of 9.84%, a sensitivity of 76.90%, and a specificity of 94.50%. Conclusion: Quantitative CT emphysema index LAA%-950 in the inspiratory phase, LAA%-910 in the expiratory phase, and PRMEmph% in biphasic can objectively evaluate emphysema in patients with mild to moderate COPD, among which PRMEmph% is the best evaluation index.

  • 图  1   男,58岁,GOLD 1级

    Figure  1.   Male, 58 years old, GOLD grade 1

    图  3   男,63岁,GOLD 2级。正常对照受试者与轻中度COPD患者PRMEmph%(红色区域)存在差异,轻中度COPD患者病变明显加重

    Figure  3.   Male, 63 years old, GOLD grade 2. There was a difference in PRMEmph% (red area) between normal controls and patients with mild to moderate COPD, and the lesions of patients with mild to moderate COPD were significantly aggravated

    图  2   女,57岁,正常对照受试者

    Figure  2.   Female, 57 years old, normal control subject

    图  4   CT定量参数区分轻中度COPD患者肺气肿的ROC

    Figure  4.   ROC of CT quantitative parameters to differentiate emphysema in patients with mild to moderate COPD

    表  1   一般资料结果比较

    Table  1   Comparison of general information and results

    项目正常对照组(n=55)轻中度COPD患者(n=52)统计检验
    $t/ {\chi }^{2}/Z $P
      年龄/岁58.130±8.228 58.700±9.622 -0.735 0.464
      性别(男/女)53/240/128.8830.003
      BMI/(kg/m224.573±2.975 23.380±2.507 1.6840.096
      吸烟指数400.000(392.000)655.000(800.000)-3.327 0.001
      FVC/L3.461±0.7693.270±1.0521.2480.215
      FEV1%/%81.570±14.39569.640±13.6543.0080.003
      FEV1/FVC/%81.030±10.00058.880±9.771 12.236 <0.001
    注:正态资料用$\bar{x}$±s表示,偏态资料用M(Q)表示。
    下载: 导出CSV

    表  2   正常对照与轻中度COPD组间CT定量指标比较

    Table  2   Comparison of CT quantitative indexes between the normal control and mild to moderate COPD groups

    项目正常对照组(n=55)轻中度COPD患者(n=52)统计检验
    ZP
    吸气相LAA%-950/% 19.210(7.890) 28.160(12.080)-4.323<0.001
    呼气相LAA%-910/% 10.380(10.360)26.210(26.680)-6.439<0.001
    PRMEmph%/%    4.055(3.570)15.610(18.590)-6.697<0.001
    PRMfSAD%/%    14.685(11.640)27.810(15.280)-4.806<0.001
    PRMNormal%/%    59.615(15.120)37.340(37.490)-5.273<0.001
    注:偏态资料用M(Q)表示。
    下载: 导出CSV

    表  3   CT定量参数与肺功能的相关性

    Table  3   Correlations between CT quantitative parameters and pulmonary function

    CT定量参数相关系数及其检验rSP
    FVC/LFEV1%/%FEV1/FVC/%
    吸气相LAA%-950/% 0.044(0.655)-0.150(<0.122)-0.512(<0.001)
    呼气相LAA%-910/%-0.301(0.002)-0.394(<0.001)-0.668(<0.001)
    PRMEmph%/%    -0.269(0.005)-0.361(<0.001)-0.696(<0.001)
    下载: 导出CSV
  • [1]

    LABAKI W W, ROSENBERG S R. Chronic obstructive pulmonary disease[J]. Annals of Internal Medicine, 2020, 173(3): ITC17−ITC32. doi: 10.7326/AITC202008040

    [2]

    HALPIN D M G, CELLI B R, CRINER G J, et al. The GOLD Summit on chronic obstructive pulmonary disease in low- and middle-income countries[J]. International Journal of Tuberculosis and Lung Disease, 2019, 23(11): 1131−1141. doi: 10.5588/ijtld.19.0397

    [3] 李小平, 欧阳辉, 袁浩. 慢性阻塞性肺疾病与体质量指数、甘油三酯、胆固醇的相关性研究[J]. 国际呼吸杂志, 2021,41(7): 489−493. doi: 10.3760/cma.j.cn131368-20200604-00472

    LI X P, OUYANG H, YUAN H. Study on the relationship between chronic obstructive pulmonary disease and body mass index, triglyceride and cholesterol[J]. International Journal of Respiration, 2021, 41(7): 489−493. (in Chinese). doi: 10.3760/cma.j.cn131368-20200604-00472

    [4]

    ZHOU J, LI X, WANG X, et al. Accuracy of portable spirometers in the diagnosis of chronic obstructive pulmonary disease a Meta-analysis[J]. NPJ Primary Care Respiratory Medicine, 2022, 32(1): 15. doi: 10.1038/s41533-022-00275-x

    [5]

    ANDREEVA E, POKHAZNIKOVA M, LEBEDEV A, et al. Spirometry is not enough to diagnose COPD in epidemiological studies: A follow-up study[J]. NPJ Primary Care Respiratory Medicine, 2017, 27(1): 62. doi: 10.1038/s41533-017-0062-6

    [6]

    GRENIER P A. Emphysema at CT in smokers with normal spirometry: Why it is clinically significant[J]. Radiology, 2020, 296(3): 650−651. doi: 10.1148/radiol.2020202576

    [7] 师美娟, 沈聪, 于楠, 等. 基于CT定量探讨不同级别慢性阻塞性肺疾病患者肺气肿肺叶分布[J]. 西安交通大学学报(医学版), 2019,40(2): 182−186. doi: 10.7652/jdyxb201902003

    SHI M J, SHEN C, YU N, et al. Quantitative study of lobar distribution of emphysema in patients with different grades of chronic obstructive pulmonary disease based on CT[J]. Journal of Xi'an Jiaotong University (Medical Sciences), 2019, 40(2): 182−186. (in Chinese). doi: 10.7652/jdyxb201902003

    [8]

    GALBÁN C J, CHENEVERT T L, MEYER C R, et al. The parametric response map is an imaging biomarker for early cancer treatment outcome[J]. Nature Medicine, 2009, 15(5): 572−576. doi: 10.1038/nm.1919

    [9] 金晨望, 梁志冉, 段海峰, 等. 基于体素的空气潴留定量测量方法的建立及初步临床应用[J]. 中华放射学杂志, 2019,(1): 21−25. doi: 10.3760/cma.j.issn.1005-1201.2019.01.006

    JIN C W, LIANG Z R, DUAN H F, et al. Establishment and preliminary clinical application of voxel-based quantitative measurement of air retention[J]. Chinese Journal of Radiology, 2019, (1): 21−25. (in Chinese). doi: 10.3760/cma.j.issn.1005-1201.2019.01.006

    [10] 黄晓旗, 牛媛, 雷禹, 等. 基于CT双气相定量研究吸烟合并慢性阻塞性肺疾病患者的肺叶小气道病变及肺气肿损伤程度[J]. 中华放射学杂志, 2022,56(5): 536−541. doi: 10.3760/cma.j.cn112149-20210428-00418

    HUANG X Q, NIU Y, LEI Y, et al. Quantitative study on the degree of small airway disease and emphysema injury in pulmonary lobes of patients with smoking combined with chronic obstructive pulmonary disease based on biphasic CT[J]. Chinese Journal of Radiology, 2022, 56(5): 536−541. (in Chinese). doi: 10.3760/cma.j.cn112149-20210428-00418

    [11] 黄晓旗, 祁鑫华, 王雷, 等. 基于KARL迭代算法对COPD低剂量CT扫描条件下肺气肿定量测量的影响[J]. 西安交通大学学报(医学版), 2020, 41(3): 410-414, 467.

    HUANG X Q, QI X H, WANG L, et al. Effect of KARL iterative algorithm on quantitative measurement of emphysema under COPD low dose CT scan[J]. Journal of Xi'an Jiaotong University (Medical Sciences), 2020, 41(3): 410-414, 467. (in Chinese).

    [12] 黄晓旗, 闫苗苗, 王雷, 等. 基于呼气相不同阈值分析慢性阻塞性肺疾病严重程度与肺功能的相关性[J]. 中国医学影像技术, 2020,36(3): 350−355. doi: 10.13929/j.issn.1003-3289.2020.03.006

    HUANG X Q, YAN M M, WANG L, et al. Analysis of the correlation between severity of chronic obstructive pulmonary disease and pulmonary function based on different expiratory thresholds[J]. Chinese Journal of Medical Imaging Technology, 2020, 36(3): 350−355. (in Chinese). doi: 10.13929/j.issn.1003-3289.2020.03.006

    [13] 梁志冉, 师美娟, 段海峰, 等. 基于双气相定量CT评估无症状青年女性空气潴留程度的研究[J]. 实用放射学杂志, 2017,33(12): 1831−1835. doi: 10.3969/j.issn.1002-1671.2017.12.005

    LIANG Z R, SHI M J, DUAN H F, et al. Evaluation of air retention in asymptomatic young women based on biphasic quantitative CT[J]. Journal of Practical Radiology, 2017, 33(12): 1831−1835. (in Chinese). doi: 10.3969/j.issn.1002-1671.2017.12.005

    [14] 梁瑞鹏, 张秀富, 王芋霖, 等. 低剂量CT在早期肺癌筛查中的研究进展[J]. 医学综述, 2021,27(20): 4113−4117. doi: 10.3969/j.issn.1006-2084.2021.20.028

    LIANG R P, ZHANG X F, WANG Y L, et al. Research progress of low-dose CT in early lung cancer screening[J]. Medical Recapitulate, 2021, 27(20): 4113−4117. (in Chinese). doi: 10.3969/j.issn.1006-2084.2021.20.028

    [15]

    BOES J L, BULE M, HOFF B A, et al. The impact of sources of variability on parametric response mapping of lung CT scans[J]. Tomography, 2015, 1(1): 69−77. doi: 10.18383/j.tom.2015.00148

    [16]

    GALBÁN C J, HAN M K, BOES J L, et al. Computed tomography-based biomarker provides unique signature for diagnosis of COPD phenotypes and disease progression[J]. Nature Medicine, 2012, 18(11): 1711−1715. doi: 10.1038/nm.2971

    [17]

    Global Strategy for the Diagnosis, Management, and Prevention of Chronic Obstructive Pulmonary Disease (2023 REPORT)[EB/OL]. (2022-11-16) [2023-04-07]. https://www.goldcopd.org.

    [18]

    CHENG T, LI Y, PANG S, et al. Emphysema extent on computed tomography is a highly specific index in diagnosing persistent airflow limitation: A real-world study in China[J]. International Journal of Chronic Obstructive Pulmonary Disease, 2018, 14: 13−26. doi: 10.2147/COPD.S157141

    [19] 郭佑民, 沈聪. CT定量技术在慢性阻塞性肺疾病中的研究现状与展望[J]. 西安交通大学学报(医学版), 2019,40(2): 173−177. doi: 10.7652/jdyxb201902001

    GUO Y M, SHEN C. Research status and prospect of CT quantitative technology in chronic obstructive pulmonary disease[J]. Journal of Xi'an Jiaotong University (Medical Sciences), 2019, 40(2): 173−177. (in Chinese). doi: 10.7652/jdyxb201902001

    [20]

    PARK J, KIM E K, LEE S H, et al. Phenotyping COPD Patients with emphysema distribution using quantitative CT measurement; more severe airway involvement in lower dominant emphysema[J]. International Journal of Chronic Obstructive Pulmonary Disease, 2022, 17: 2013−2025. doi: 10.2147/COPD.S362906

    [21]

    NTRITSOS G, FRANEK J, BELBASIS L, et al. Gender-specific estimates of COPD prevalence: A systematic review and metaanalysis[J]. International Journal of Chronic Obstructive Pulmonary Disease, 2018, 13: 1507−1514. doi: 10.2147/COPD.S146390

    [22]

    FOREMAN M G, ZHANG L, MURPHY J, et al. Early-onset chronic obstructive pulmonary disease is associated with female sex, maternal factors, and African American race in the COPD Gene study[J]. American Journal of Respiratory and Critical Care Medicine, 2011, 184(4): 414−420. doi: 10.1164/rccm.201011-1928OC

    [23]

    AMAZA I P, O'SHEA A M J, FORTIS S, et al. Discordant quantitative and visual CT assessments in the diagnosis of emphysema[J]. International Journal of Chronic Obstructive Pulmonary Disease, 2021, 16: 1231−1242. doi: 10.2147/COPD.S284477

    [24] 王雯婷, 王晓华, 贺蓓, 等. CT参数效应图在慢性阻塞性肺疾病诊疗中的应用进展[J]. 中华结核和呼吸杂志, 2021,44(4): 409−412. doi: 10.3760/cma.j.cn112147-20200712-00795

    WANG W T, WANG X H, HE B, et al. Progress in the application of CT parameter effect map in the diagnosis and treatment of chronic obstructive pulmonary disease[J]. Chinese Journal of Tuberculosis and Respiratory Diseases, 2021, 44(4): 409−412. (in Chinese). doi: 10.3760/cma.j.cn112147-20200712-00795

    [25]

    VASILESCU D M, MARTINEZ F J, MARCHETTI N, et al. Noninvasive imaging biomarker identifies small airway damage in severe chronic obstructive pulmonary disease[J]. American Journal of Respiratory and Critical Care Medicine, 2019, 200(5): 575−581. doi: 10.1164/rccm.201811-2083OC

    [26]

    HWANG H J, SEO J B, LEE S M, et al. New method for combined quantitative assessment of air-trapping and emphysema on chest computed tomography in chronic obstructive pulmonary disease: Comparison with parametric response mapping[J]. Korean Journal of Radiology, 2021, 22(10): 1719−1729. doi: 10.3348/kjr.2021.0033
