能谱增强CT诊断继发性骨骼肌滤泡性淋巴瘤的病例分析

徐海芸, 杨烁慧

徐海芸, 杨烁慧. 能谱增强CT诊断继发性骨骼肌滤泡性淋巴瘤的病例分析[J]. CT理论与应用研究(中英文), 2024, 33(2): 221-227. DOI: 10.15953/j.ctta.2023.022.
引用本文: 徐海芸, 杨烁慧. 能谱增强CT诊断继发性骨骼肌滤泡性淋巴瘤的病例分析[J]. CT理论与应用研究(中英文), 2024, 33(2): 221-227. DOI: 10.15953/j.ctta.2023.022.
XU H Y, YANG S H. Spectral Computed Tomography for the Diagnosis of Secondary Skeletal Muscle Follicular Lymphoma: A Case Analysis[J]. CT Theory and Applications, 2024, 33(2): 221-227. DOI: 10.15953/j.ctta.2023.022. (in Chinese).
Citation: XU H Y, YANG S H. Spectral Computed Tomography for the Diagnosis of Secondary Skeletal Muscle Follicular Lymphoma: A Case Analysis[J]. CT Theory and Applications, 2024, 33(2): 221-227. DOI: 10.15953/j.ctta.2023.022. (in Chinese).

能谱增强CT诊断继发性骨骼肌滤泡性淋巴瘤的病例分析

基金项目: 上海市“医苑新星”青年医学人才培养资助计划——医学影像项目(SHWRS(2020)-087)。
详细信息
    作者简介:

    徐海芸: 女,上海交通大学影像医学与核医学硕士研究生,上海中医药大学附属市中医医院放射科住院医师,主要从事骨肌影像诊断,E-mail:xhy101941@163.com

    通讯作者:

    杨烁慧: 女,复旦大学影像医学与核医学博士,上海中医药大学附属市中医医院放射科副主任医师,主要从事医学影像诊断工作,E-mail:caddie_yang1980@aliyun.com

  • 中图分类号: R  814

Spectral Computed Tomography for the Diagnosis of Secondary Skeletal Muscle Follicular Lymphoma: A Case Analysis

  • 摘要:

    滤泡性淋巴瘤是非霍奇金淋巴瘤的常见类型之一,继发性骨骼肌滤泡性淋巴瘤属于结外淋巴瘤,临床少见,诊断较困难,能谱增强CT成像可帮助进行影像学诊断。2021年,1名52岁的男性因发现左侧腹股沟区肿物2月就诊,经肿物穿刺活检术、颈部淋巴结清扫术及骨髓穿刺活检术后病理明确诊断为滤泡性淋巴瘤Ⅰ级、累及骨髓。后患者腰痛进行性加重2月,行腰椎能谱增强CT提示右侧腰大肌与腹膜后肿大淋巴结为同源性病灶,考虑右侧腰大肌淋巴瘤浸润可能性大。能谱增强CT成像是一种无创、便捷、准确的影像学诊断方法,通过重建、比较不同组织的能谱曲线确定肿块性质,可以帮助诊断结外淋巴瘤,对判断病变范围、指导临床治疗方案具有重要价值。

    Abstract:

    Follicular lymphoma (FL) is one of the frequent varieties of non-Hodgkin's lymphoma (NHL). Secondary skeletal muscle FL is an uncommon extra-nodal lymphoma that is more challenging to identify. Spectral CT imaging can aid in the diagnosis of it. A 52-year-old man who had a bulge in his left inguinal area for two months in 2021. Following a mass aspiration biopsy, cervical lymph node dissection and a bone marrow aspiration biopsy, the patient was diagnosed as follicular lymphoma grade I with bone marrow involvement. Later, the patient had progressive worsening of low back pain for 2 month and underwent a lumbar spectral enhanced-CT scan, which demonstrated the right psoas major muscle and the retroperitoneal swollen lymph nodes were discovered to be homologous lesions, indicating the lymphoma infiltration of the right psoas major muscle. Spectral enhanced-CT is a non-invasive, practical, and reliable alternative technique. By reconstructing and comparing the energy spectrum curves of different tissues to shed light on the nature of the mass, it can aid in the diagnosis of extra-nodal lymphoma, which is of great value in determining the extent of the lesion and guiding the clinical treatment plan.

  • 图  1   上腹部CT平扫:双侧腰大肌形态、密度无明显差异;腹膜后多发肿大淋巴结;脾肿大

    Figure  1.   Computed tomography (CT) scan of the upper abdomen

    图  2   腰椎MRI平扫

    (a)和(b)L1-L2水平右侧腰大肌见一肿块,呈T1WI低、T2WI稍高信号。

    Figure  2.   Lumbar spine MRI plain scan

    图  3   腰椎能谱CT增强图像

    (a)动脉晚期 ROI对应能谱曲线(蓝线代表右侧肿大腰大肌,绿线代表左侧正常腰大肌,紫线代表腹膜后肿大淋巴结)。(b)腰椎 CT平扫:腹膜后多发肿大淋巴结;右侧腰大肌较对侧明显肿胀。(c)和(d)腰椎能谱增强 CT动脉晚期轴位图像:双侧腰大肌及腹膜后肿大淋巴结ROI对应的CT值;右侧肿大腰大肌增强后强化程度略高于左侧正常腰大肌,密度均匀。

    Figure  3.   Lumbar spine spectral computed tomography (CT) image

    表  1   能谱增强CT扫描方式及参数

    Table  1   Spectral computed tomography (CT) scan modes and parameters

    扫描方式及参数名具体扫描方式及参数值扫描方式及参数名具体扫描方式及参数值
      采集体位  仰卧位,头先进   层间距  0.625 mm
      扫描方向、范围  自胸椎下缘向下扫描至骶椎   管电压  GSI模式(瞬时切换80 kVp、140 kVp)
      探测器宽度  64×0.625 mm   管电流  自动毫安模式(200~650 mA,NI:9)
      扫描方法  经验法   矩阵  512×512
      层厚  0.625 mm   机架旋转时间  0.6 s/r
    下载: 导出CSV

    表  2   双侧腰大肌及腹膜后肿大淋巴结的KVP40-70KVP40-100KVP40-140

    Table  2   KVP40-70, KVP40-100 and KVP40-140 of the bilateral psoas major muscle and enlarged retroperitoneal lymph nodes

    项目KVP40-70KVP40-100KVP40-140
    右侧肿大腰大肌 2.381.500.99
    左侧正常腰大肌 1.410.890.60
    后腹膜肿大淋巴结2.761.761.14
    下载: 导出CSV
  • [1]

    CHUN C W, JEE W H, PARK H J, et al. MRI features of skeletal muscle lymphoma[J]. American Journal of Roentgenology, 2010, 195(6): 1355−1360. doi: 10.2214/AJR.09.3904

    [2]

    BELMONTE G, CALDARELLA C, HOHAUS S, et al. Muscle recurrence of a primarily nodal follicular lymphoma studied by contrast-enhanced 18F-FDG PET/CT[J]. Clinical Nuclear Medicine, 2020, 45(1): 65−67. doi: 10.1097/RLU.0000000000002839

    [3]

    HONGSAKUL K, LAOHAWIRIYAKAMOL T, KAYASUT K. A rare case of primary muscular non-Hodgkin's lymphoma and a review of how imaging can assist in its diagnosis[J]. Singapore Medical Journal, 2013, 54(9): e179−182. doi: 10.11622/smedj.2013179

    [4] 魏一娟, 贾飞, 苏蕾, 等. 能谱CT定量参数值鉴别鼻咽淋巴瘤及鼻咽癌的价值[J]. 中国医学计算机成像杂志, 2021,27(6): 500−504. doi: 10.3969/j.issn.1006-5741.2021.06.006

    WEI Y J, JIA F, SU L, et al. Clinical value of quantitative parameters by spectral CT in distinguishing nasopharyngeal lymphoma and nasopharyngeal carcinoma[J]. Chinese Computed Medical Imaging, 2021, 27(6): 500−504. (in Chinese). doi: 10.3969/j.issn.1006-5741.2021.06.006

    [5]

    XIE Y, ZHANG S, LIU J, et al. Value of CT spectral imaging in the differential diagnosis of thymoma and mediastinal lymphoma[J]. British Journal of Radiology, 2019, 92(1095): 20180598. doi: 10.1259/bjr.20180598

    [6]

    TUNLAYADECHANONT P, PANYAPING T, KAEWKERD B. Role of quantitative spectral CT analysis for differentiation of orbital lymphoma and other orbital lymphoproliferative disease[J]. European Journal of Radiology, 2020, 133: 109372. doi: 10.1016/j.ejrad.2020.109372

    [7]

    YANG C B, YU N, JIAN Y J, et al. Spectral CT imaging in the differential diagnosis of small bowel adenocarcinoma from primary small intestinal lymphoma[J]. Academic Radiology, 2019, 26(7): 878−884. doi: 10.1016/j.acra.2018.08.020

    [8]

    YU C H, ZHANG R P, YANG X T, et al. Dual-energy CT perfusion imaging for differentiating invasive thymomas, thymic carcinomas, and lymphomas in adults[J]. Clinical Radiology: Journal of the Royal College of Radiologists, 2022, 77(6): e417−e424.

    [9]

    SHEN H, YUAN X, LIU D, et al. Multiparametric dual-energy CT for distinguishing nasopharyngeal carcinoma from nasopharyngeal lymphoma[J]. European Journal of Radiology, 2021, 136: 109532. doi: 10.1016/j.ejrad.2021.109532

    [10]

    GAO S, SHU H, YANG H. Imaging features of skeletal muscle lymphoma: A case report and literature review[J]. British Medical Council, 2021, 21(1): 136.

    [11]

    LIZUKA H, HARADA S, IWAO N, et al. Primary skeletal muscle peripheral T-cell lymphoma: An autopsy case report and review of the literature[J]. Internal Medicine, 2021, 60(20): 3309−3315. doi: 10.2169/internalmedicine.7391-21

    [12]

    BAQARI S A S, RAZI M, HAYAT J, et al. Classical Hodgkin's lymphoma with skeletal muscle involvement: A testing case[J]. Journal of the College of Physicians and Surgeons Pakistan, 2019, 29(1): 81−83. doi: 10.29271/jcpsp.2019.01.81

    [13]

    GONZALEZ-BENAVIDES N, GARZA C D L, RODRIGUEZ-VIVIAN C, et al. Skeletal muscle diffuse large B-cell lymphoma in the gluteal region[J]. Turkish Journal of Hematology, 2018, 35(4): 310−311.

    [14]

    PECORELLA I, FERRARI A, TORNESE A, et al. Primary anaplastic large T-cell lymphoma of the psoas muscle[J]. Polish Journal of Pathology, 2021, 72(1): 89−96. doi: 10.5114/pjp.2021.106448

    [15]

    LIM S, BAEK H J, KANG Y H. A case report of primary extranodal diffuse large B-cell lymphoma involving the masseter muscle: Histological-radiological correlation[J]. Current Medical Imaging, 2022, 19(7): 788−792.

    [16]

    SO A, NICOLAOU S. Spectral computed tomography: Fundamental principles and recent developments[J]. Korean Journal of Radiology, 2021, 22(1): 86−96. doi: 10.3348/kjr.2020.0144

    [17]

    ZELENETZ A D, GORDON L I, CHANG J E, et al. NCCN guidelines® insights: B-Cell lymphomas, version 5.2021[J]. Journal of the National Comprehensive Cancer Network, 2021, 19(11): 1218−1230. doi: 10.6004/jnccn.2021.0054
