56例特发性正常压力脑积水患者的临床和MRI特征分析

吴倩, 何文杰, 张协军, 夏军

吴倩, 何文杰, 张协军, 等. 56例特发性正常压力脑积水患者的临床和MRI特征分析[J]. CT理论与应用研究(中英文), 2024, 33(2): 167-174. DOI: 10.15953/j.ctta.2023.095.
引用本文: 吴倩, 何文杰, 张协军, 等. 56例特发性正常压力脑积水患者的临床和MRI特征分析[J]. CT理论与应用研究(中英文), 2024, 33(2): 167-174. DOI: 10.15953/j.ctta.2023.095.
WU Q, HE W J, ZHANG X J, et al. Clinical and MRI Characteristics of 56 Patients with Idiopathic Normal Pressure Hydrocephalus[J]. CT Theory and Applications, 2024, 33(2): 167-174. DOI: 10.15953/j.ctta.2023.095. (in Chinese).
Citation: WU Q, HE W J, ZHANG X J, et al. Clinical and MRI Characteristics of 56 Patients with Idiopathic Normal Pressure Hydrocephalus[J]. CT Theory and Applications, 2024, 33(2): 167-174. DOI: 10.15953/j.ctta.2023.095. (in Chinese).

56例特发性正常压力脑积水患者的临床和MRI特征分析

基金项目: 国家自然科学基金(机器学习构建特发性正常压力脑积水分流术预后模型:基于大脑结构与连接的磁共振研究(82171913))。
详细信息
    作者简介:

    吴倩: 女,广州医科大学放射影像学专业硕士研究生,主要研究方向为头颈部及中枢神经系统影像诊断,E-mail:qianwu400@163.com

    通讯作者:

    夏军: 男,深圳市第二人民医院放射科主任医师,主要研究方向为头颈部及中枢神经系统影像诊断,E-mail:xiajun2003sz@aliyun.com

  • 中图分类号: R  445

Clinical and MRI Characteristics of 56 Patients with Idiopathic Normal Pressure Hydrocephalus

  • 摘要:

    目的:对行手术确诊的特发性正常压力脑积水患者的临床和MRI表现进行分析和总结,研究其临床、MRI特征以提高对该疾病的认识。方法:回顾性分析56例行分流术确诊的特发性正常压力脑积水(iNPH)患者临床和术前MR(包括3DT1WI、T2WI、T2 FLAIR)资料,对iNPH常见MR影像征象进行评估和描述。结果:56例iNPH患者中,步态障碍、认知障碍及尿失禁的发生率分别为91.1%、60.7%及42.9%,经典三联征为23.2%;常见合并症依次为高血压(51.8%)、糖尿病(28.6%)及帕金森病(PD)(12.5%)。对56例iNPH患者MR图像进行分析,82.1% 患者胼胝体角呈锐角,39.3% 患者蛛网膜下腔不成比例扩大征象(DESH)阳性,DESH评分平均得分(5.24±1.27)。结论:iNPH确诊患者最常合并高血压、糖尿病和PD,经典三联征较少,典型的MR征象阳性率不高,阴性患者的诊断和预后预测仍然存在挑战,应结合其他临床检查明确诊断和治疗。

    Abstract:

    Objective: To analyze and summarize the clinical and MRI manifestations of patients with idiopathic normal pressure hydrocephalus (iNPH) diagnosed via surgery in order to improve the understanding of this disease. Methods: We performed a retrospective analysis of the clinical and preoperative MR (including 3DT1WI, T2WI, and T2 FLAIR) data of 56 patients with iNPH diagnosed via shunt surgery at our hospital to evaluate and describe MR linear parameters and common radiological features. Results: Among the 56 patients with iNPH, 91.1%, 60.7%, and 42.9% showed gait disturbance, cognitive impairment, and urinary disturbance, respectively; the classical triad accounted for 23.2%. The most common comorbidities were hypertension (51.8%), diabetes (28.6%), and PD (12.5%). In the analysis of the 56 patients’ MR images, 82.1% had acute callosal angle and 39.3%, positive disproportionately enlarged subarachnoid space (DESH) signs , with a mean DESH score of (5.24±1.27). Conclusion: Patients with confirmed iNPH most often also have hypertension, diabetes mellitus, and PD. The classical triad is less frequent, and the positive rate of typical MR signs is not high. Thus, the accurate diagnosis and prognosis prediction of negative patients remains challenging and should be combined with other clinical examinations to clarify the diagnosis and treatment.

  • 图  1   特发性正常压力脑积水。男,67岁,线性参数的测量方法示意图

    (a)3DT1WI横断面,侧脑室扩大指数的测量;(b)T2 FLAIR,侧脑室颞角直径测量;(c)3DT1WI横断面,三脑室最大直径测量;(d)和(e)3DT1WI矢、冠状面,胼胝体角(CA)的测量,取经过后联合且垂直于前后联合连线的平面测量两侧侧脑室的夹角。

    Figure  1.   Idiopathic normal pressure hydrocephalus. Male, 67 years old, measurement of linear parameters

    图  2   特发性正常压力脑积水。男,71岁,脑白质MR信号改变及DESH征象评估

    (a)T2 FLAIR横断面,脑深部白质高信号(DWMH)(粗箭头);(b)T2 FLAIR横断面,脑室周围高信号(PVH)(粗箭头);(c)T2 FLAIR冠状面,DESH征(蛛网膜下腔不成比例扩大),即大脑凸面挤压效应(粗箭头)同时合并双侧裂池扩大(细箭头);(d)3DT1WI横断面,大脑顶叶局部脑沟扩大(粗箭头)。

    Figure  2.   Idiopathic normal pressure hydrocephalus. Male, 71 years old, white matter MR signal changes and evaluation of DESH sign image

    表  1   56例iNPH患者的一般资料及临床表现

    Table  1   General data and clinical manifestations of 56 patients with iNPH

    指标结果
          年龄/(岁,$x\pm s $)70.8±6.4
          年龄段/例(%)     60~6924(42.9)
         70~7927(48.2)
         ≥805(8.9)
          性别(男)/例(%)35(62.5)
          病程/(月,$x\pm s $)26.8±3.5
          临床症状/例(%)     步态障碍51(91.1)
         认知障碍34(60.7)
         排尿障碍24(42.9)
         步态+认知障碍29(51.8)
         步态+排尿障碍21(37.5)
         认知+排尿障碍16(28.6)
         三联征13(23.2)
          共病情况/例(%)     高血压29(51.8)
         糖尿病16(28.6)
         帕金森病 7(12.5)
         阿尔兹海默病1(1.8)
         冠心病及其合并症3(5.4)
         脑血管疾病及其合并症4(7.2)
         其他5(8.9)
    下载: 导出CSV

    表  2   56例iNPH患者的MR影像表现

    Table  2   MR imaging manifestations of 56 patients with iNPH

    指标结果
         EI($x\pm s $)0.35±0.03
         第三脑室直径/(mm,$x\pm s $)14.6±3.4
         颞角直径/(mm,$x\pm s $)9.6±4.5
         CA($x\pm s $)72.2±14.6
         评分分级/例(%)      <90°,2分46(82.1)
         ≥90°,≤100°,1分5(8.9)
         >100°,0分5(8.9)
         大脑凸面挤压效应/例(%)23(41.1)
         侧裂池扩大/例(%)31(55.4)
         局部脑沟扩大/例(%)36(64.3)
         DWMH($x\pm s $)1.9±0.3
         PVH($x\pm s $)1.5±0.5
         DESH征/例(%)22(39.3)
         DESH评分($x\pm s $)5.24±1.27
         DESH评分分级/例(%)     3分4(7.1)
         4分15(26.8)
         5分10(17.9)
         6分19(33.9)
         7分 6(10.7)
         8分2(3.6)
    注:CA为胼胝体角;DWMH为深部白质高信号;PVH为脑室周围高信号;DESH征为蛛网膜下腔不成比例扩大的脑积水征象。
    下载: 导出CSV
  • [1]

    NAKAJIMA M, YAMADA S, MIYAJIMA M, et al. Guidelines for management of idiopathic normal pressure hydrocephalus (Third Edition): Endorsed by the Japanese society of normal pressure hydrocephalus[J]. Neurologia Medico-Chirurgica, 2021, 61(2): 63−97. DOI: 10.2176/nmc.st.2020-0292.

    [2]

    MISKIN N, PATEL H, FRANCESCHI A M, et al. Diagnosis of normal-pressure hydrocephalus: Use of traditional measures in the era of volumetric MR imaging[J]. Radiology, 2017, 285(1): 197-205. DOI:10.1148/radiol.2017161216.

    [3]

    KITAGAKI H, MORI E, ISHII K, et al. CSF spaces in idiopathic normal pressure hydrocephalus: Morphology and volumetry[J]. American Journal of Neuroradiology, 1998, 19(7): 1277−1284.

    [4] 王长春, 王作伟, 袁庆国, 等. 老年特发性正常压力脑积水患者的手术治疗及中期随访[J]. 中华老年医学杂志, 2011,30(8): 664−666. DOI: 10.3760/cma.j.issn.0254-9026.2011.08.014.

    WANG C C, WANG Z W, YUAN Q G, et al. The surgical treatment of elderly patients with idiopathic normal pressure hydrocephalus and medium-term follow-up[J]. Journal of the Chinese Elderly Medical Journal, 2011, 30(8): 664−666. DOI: 10.3760/cma.j.issn.0254-9026.2011.08.014. (in Chinese).

    [5]

    TOMA A K, HOLL E, KITCHEN N D, et al. Evans' index revisited: The need for an alternative in normal pressure hydrocephalus[J]. Neurosurgery, 2011, 68(4): 939−944. DOI: 10.1227/NEU.0b013e318208f5e0.

    [6]

    ISHII K, KANDA T, HARADA A, et al. Clinical impact of the callosal angle in the diagnosis of idiopathic normal pressure hydrocephalus[J]. European Radiology, 2008, 18(11): 2678−2683. DOI: 10.1007/s00330-008-1044-4.

    [7]

    FAZEKAS F, CHAWLUK J B, ALAVI A, et al. MR signal abnormalities at 1.5T in Alzheimer's dementia and normal aging[J]. American Journal of Neuroradiology, 1987, 149(2): 351−356. DOI: 10.2214/ajr.149.2.351.

    [8]

    MIYAZAKI K, ISHII K, HANAOKA K, et al. The tight medial and high convexity subarachnoid spaces is the first finding of idiopathic normal pressure hydrocephalus at the preclinical stage[J]. Neurologia Medico-Chirurgica, 2019, 59(11): 436−443. DOI: 10.2176/nmc.oa.2019-0133.

    [9]

    SASAKI M, HONDA S, YUASA T, et al. Narrow CSF space at high convexity and high midline areas in idiopathic normal pressure hydrocephalus detected by axial and coronal MRI[J]. Neuroradiology, 2008, 50(2): 117−122. DOI: 10.1007/s00234-007-0318-x.

    [10]

    VIRHAMMAR J, LAURELL K, CESARINI K G, et al. Preoperative prognostic value of MRI findings in 108 patients with idiopathic normal pressure hydrocephalus[J]. American Journal of Neuroradiology, 2014, 35(12): 2311−2318. DOI: 10.3174/ajnr.A4046.

    [11]

    HOLODNY A I, GEORGE A E, de-LEON M J, et al. Focal dilation and paradoxical collapse of cortical fissures and sulci in patients with normal-pressure hydrocephalus[J]. Journal of Neurosurgery, 1998, 89(5): 742−747. DOI: 10.3171/jns.1998.89.5.0742.

    [12]

    SHINODA N, HIRAI O, HORI S, et al. Utility of MRI-based disproportionately enlarged subarachnoid space hydrocephalus scoring for predicting prognosis after surgery for idiopathic normal pressure hydrocephalus: Clinical research[J]. Journal of Neurosurgery, 2017, 127(6): 1436−1442. DOI: 10.3171/2016.9.JNS161080.

    [13] 中华医学会神经外科学分会, 中华医学会神经病学分会, 中国神经外科重症管理协作组. 中国特发性正常压力脑积水诊治专家共识(2016)[J]. 中华医学杂志, 2016,96(21): 1635−1638. doi: 10.3760/cma.j.issn.0376-2491.2016.021.003
    [14]

    ARUGA S, KUWANA N, SHIROKI Y, et al. Effect of cerebrospinal fluid shunt surgery on lower urinary tract dysfunction in idiopathic normal pressure hydrocephalus[J]. Neurourology and Urodynamics, 2018, 37(3): 1053−1059. DOI: 10.1002/nau.23399.

    [15] 李勇, 方旭昊, 毛仁玲, 等. 老年正常压力脑积水患者与脑卒中患者三维步态参数的差异性研究[J]. 老年医学与保健, 2017,23(4): 324−327. doi: 10.3969/j.issn.1008-8296.2017.04.024

    LI Y, FANG X H, MAO R L, et al. Difference of 3-dimensional gait parameters between the elderly patients with normal pressure hydrocephalus and the patients with hemiplegia after stroke[J]. Geriatrics and Health Care, 2017, 23(4): 324−327. (in Chinese). doi: 10.3969/j.issn.1008-8296.2017.04.024

    [16] 方旭昊, 舒卫权, 高幸, 等. 急诊跌倒老年人群特发性正常压力脑积水诊治的初步探索[J]. 老年医学与保健, 2018,24(1): 8−11, 21. doi: 10.3969/j.issn.1008-8296.2018.01.004

    FANG X H, SHU W Q, GAO X, et al. Preliminary exploration of the diagnosis and treatment of iNPH in emergency elderly patients with falls[J]. Geriatrics and Health Care, 2018, 24(1): 8−11, 21. (in Chinese). doi: 10.3969/j.issn.1008-8296.2018.01.004

    [17]

    KURIYAMA N, MIYAJIMA M, NAKAJIMA M, et al. Nationwide hospital-based survey of idiopathic normal pressure hydrocephalus in Japan: Epidemiological and clinical characteristics[J]. Brain and Behavior, 2017, 7(3): e635. DOI: 10.1002/brb3.635.

    [18]

    KAMOHARA C, NAKAJIMA M, KAWAMURA K, et al. Neuropsychological tests are useful for predicting comorbidities of idiopathic normal pressure hydrocephalus[J]. Acta Neurologica Scandinavica, 2020, 142(6): 623−631. DOI: 10.1111/ane.13306.

    [19]

    HUDSON M, NOWAK C, GARLING R J, et al. Comorbidity of diabetes mellitus in idiopathic normal pressure hydrocephalus: A systematic literature review[J]. Fluids and Barriers of the CNS, 2019, 16(1): 5. DOI:10.1186/s12987-019-0125-x.

    [20]

    ANDREN K, WIKKELSO C, SUNDSTROM N, et al. Long-term effects of complications and vascular comorbidity in idiopathic normal pressure hydrocephalus: A quality registry study[J]. Journal of Neurology, 2018, 265(1): 178−186. DOI: 10.1007/s00415-017-8680-z.

    [21]

    WILLIAMS M A, RELKIN N R. Diagnosis and management of idiopathic normal pressure hydrocephalus[J]. Neurology Clinical Practice, 2013, 3(5): 375−385. doi: 10.1212/CPJ.0b013e3182a78f6b

    [22]

    ALLALI G, GARIBOTTO V, ASSAL F. Parkinsonism differentiates idiopathic normal pressure hydrocephalus from its mimics[J]. Journal of Alzheimer's Disease, 2016, 54(1): 123−127. DOI: 10.3233/JAD-160428.

    [23]

    LEMAY M, NEW P F. Radiological diagnosis of occult normal-pressure hydrocephalus[J]. Radiology, 1970, 96(2): 347−358. DOI: 10.1148/96.2.347.

    [24] 方旭昊, 舒卫权, 何文杰, 等. DESH评分预测特发性正常压力脑积水脑脊液放液试验的效果[J]. 老年医学与保健, 2020,26(4): 583−586, 601. DOI: 10.3969/j.issn.1008-8296.2020.04.019.

    FANG X H, SHU W Q, HE W J, et al. Effect of DESH score on prediction of cerebrospinal fluid drainage test of idiopathic normal pressure hydrocephalus[J]. Geriatrics and Health Care, 2020, 26(4): 583−586, 601. DOI: 10.3969/j.issn.1008-8296.2020.04.019. (in Chinese).
