邓家秀, 张永东, 冯丰吟, 刘娟, 陈玉英. CT灌注成像及动态增强扫描在肺部结节影像诊断中的价值初步探讨[J]. CT理论与应用研究, 2008, 17(2): 66-73.
引用本文: 邓家秀, 张永东, 冯丰吟, 刘娟, 陈玉英. CT灌注成像及动态增强扫描在肺部结节影像诊断中的价值初步探讨[J]. CT理论与应用研究, 2008, 17(2): 66-73.
DENG Jia-xiu, ZHANG Yong-dong, FENG Feng-yin, LIU Juan, CHEN Yu-ying. A Preliminary Study of CT Perfusion Imaging and Dynamic Enhanced for Lung Nodule[J]. CT Theory and Applications, 2008, 17(2): 66-73.
Citation: DENG Jia-xiu, ZHANG Yong-dong, FENG Feng-yin, LIU Juan, CHEN Yu-ying. A Preliminary Study of CT Perfusion Imaging and Dynamic Enhanced for Lung Nodule[J]. CT Theory and Applications, 2008, 17(2): 66-73.

CT灌注成像及动态增强扫描在肺部结节影像诊断中的价值初步探讨

A Preliminary Study of CT Perfusion Imaging and Dynamic Enhanced for Lung Nodule

  • 摘要: 目的:探讨CT动态增强扫描及灌注成像在肺部结节影像诊断中的价值。材料与方法:对34例肺部结节(恶性结节17例,良性结节11例,活动性炎症结节6例)进行单排螺旋CT动态增强扫描。对45例肺部结节(恶性结节24例,良性结节13例,活动性炎症结节8例)进行双排螺旋CT灌注扫描及动态增强扫描。对增强扫描病例绘出三类型结节的动态增强时间-密度曲线;对灌注扫描病例用随机灌注软件进行分析处理,得出病灶感兴趣区血流量、血容积、平均通过时间及血管表面通透性,比较三类型结节各灌注参数之间的差异。结果:良性结节动态增强时间密度曲线低平,CT值增加约10Hu;活动性炎性结节之时间密度曲线为速升速降型,CT增强值增加约62Hu;而恶性结节为速升慢降型,CT值增加约46Hu。恶性结节和活动性炎性结节的血容积及血管表面通透性值高于良性结节,良性结节的血容积值一般小于6.5mL·100g-1,血管表面通透性值小于30mL·min-1·100g-1。结论:CT灌注成像可以提供肺内结节的血流灌注的定量信息,CT动态增强扫描及灌注成像有助于肺内结节的鉴别诊断。



    Abstract: Objective: To study the roles of CT perfusion imaging and dynamic enhanced for diagnosis of lung nodule. Methods: The dynamic contrast-enhanced CT were performed with single-slice spiral CT in 34 patients with lung nodule (including: 17 cases of malignant nodule, 11 cases of benign nodule, and 6 cases of active inflammatory nodule). The CT perfusion imaging and dynamic enhanced CT were performed with two-slice spiral CT in 45 patients with lung nodule (including: 24 cases of malignant nodule, 13 cases of benign nodule, and 8 cases of active inflammatory nodule). According to dynamic contrast-enhanced examination, CT values of the nodules at different delay time were got to describe the time-density curve in all cases. The perfusion parameters, including Blood Flow, Blood Volume, Mean Transmit Time and Permeability Surface, were acquired with body perfusion-2 software, and they were analyzed and compared among three groups of lung nodules. Results: The time-density curve of the benign pulmonary nodules was fiat with enhancement only about 10 Hu. The malignant nodule increased rapidly at early time and maintained a plateau with decreased slowly in delay phase, with enhancement of CT value about 46 Hu. Whereas the active inflammatory nodule increased rapidly and come down also rapidly, with enhancement of CT value about 62 Hu. The values of blood volume and permeability surface in malignant and active inflammatory nodule are greater than that in benign pulmonary nodules. The values of blood volume and permeability surface in benign nodules are less than 6.5 mL/100g and 30 mL/100g min, respectively. Conclusion: CT perfusion imaging can provide quantitative information of blood perfusion within lung nodules, CT perfusion imaging and dynamic enhanced CT is helpful for differentiating lung nodules.



/
