ICT切片重构模型的剖切及应用

刘晶, 张定华, 赵歆波, 毛海鹏

刘晶, 张定华, 赵歆波, 毛海鹏. ICT切片重构模型的剖切及应用[J]. CT理论与应用研究, 2004, 13(4): 60-63.
引用本文: 刘晶, 张定华, 赵歆波, 毛海鹏. ICT切片重构模型的剖切及应用[J]. CT理论与应用研究, 2004, 13(4): 60-63.
LIU Jing, ZHANG Ding-hua, ZHAO Xin-bo, MAO Hai-peng. Cutting and Application of ICT Slice Reconstructed Model[J]. CT Theory and Applications, 2004, 13(4): 60-63.
Citation: LIU Jing, ZHANG Ding-hua, ZHAO Xin-bo, MAO Hai-peng. Cutting and Application of ICT Slice Reconstructed Model[J]. CT Theory and Applications, 2004, 13(4): 60-63.

ICT切片重构模型的剖切及应用

基金项目:

Supported by Arming Preresearch Mission

详细信息
    作者简介:

    刘晶(1977-),女(汉族),西北工业大学机电学院博士研究生,主要从事工业CT、图形图像处理方面的研究。E-mail:annaliu200077@163.com;张定华(1958-),男(汉族),西北工业大学机电学院教授,博士生导师,主要研究方向为计算机辅助设计与制造、体视化技术、三维图象重建等众多领域;赵歆波(1970-),男,(满族),西北工业大学机电学院副教授,主要从事三维图象重建、计算机视觉方面的研究;毛海鹏(1976-),男(汉族),西北工业大学机电学院博士研究生,主要从事工业CT、图形图像处理方面的研究。

  • 中图分类号: TP391.41

Cutting and Application of ICT Slice Reconstructed Model

Funds:

Supported by Arming Preresearch Mission

  • 摘要: 在ICT切片重构模型的可视化中,为了分析重构模型的任意截面形状,并且观察该截面的内部结构,需要对重构模型进行剖切。本文针对剖切提出一种简单方法,该方法利用剖切面对重构模型所在的立方体图像空间进行剖切,生成交点集合,然后将空间剖切平面映射到二维图像平面上,最后计算空间剖切平面图像的灰度值,得到剖面图像。通过剖面图像,可以直观地看到内部结构形状,为后续无损检测奠定基础。
    Abstract: In order to analyze any section shape of reconstructed model and observe inner structure in the visualization of ICT slice reconstructed model, the reconstructed model is cut by the plane. A method is put forward to cutting. First cutting is done by the cutting plane to the cube image space in which reconstructed model is, intersection point set is formed, then the spacial cutting plane is mapped to 2D image plane, finally grey value of the spacial cutting plane image is calculated and the section image is got. Inner structure and shape are observed by the section image. It will establish the base for nondestructive testing.
